Specifications for
Cubi 2 Plus
Marketing Name
Marketing Name
Cubi 2 Plus
Operating System
Operating System
Windows 10 Home - MSI recommends Windows 10 Pro
CPU
CPU
6th Intel® Skylake-S power saving processor
7th Intel® Kaby Lake-S power saving processor
7th Intel® Kaby Lake-S power saving processor
Storage
Storage
1 x M.2 SSD
1 x 2.5” SATA HDD or SSD
1 x 2.5” SATA HDD or SSD
Memory
Memory
DDR4 2133MHz up to 32GB (Skylake version) (2 Slots)
DDR4 2400MHz up to 32GB (Kaby Lake version) (2 Slots)
DDR4 2400MHz up to 32GB (Kaby Lake version) (2 Slots)
I/O (Front)
I/O (Front)
1 x Mic/Audio jack
3 x USB 2.0
1 x USB 3.1 Gen1 type C
1 x Card reader
3 x USB 2.0
1 x USB 3.1 Gen1 type C
1 x Card reader
I/O (Rear)
I/O (Rear)
●Configuration 1
1 x HDMI™ out
1 x DP out
1 x RJ45
2 x USB3.1 Gen1
●Configuration 2
2 x HDMI™ out
1 x DP out
1 x RJ45
2 x USB3.1 Gen1
1 x COM port
1 x USB2.0
1 x HDMI™ out
1 x DP out
1 x RJ45
2 x USB3.1 Gen1
●Configuration 2
2 x HDMI™ out
1 x DP out
1 x RJ45
2 x USB3.1 Gen1
1 x COM port
1 x USB2.0
I/O(Top)
I/O(Top)
1 x USB2.0 with super charger
LAN
LAN
Integrated Intel® I219V Ethernet LAN 10/100/1000
Dimension (WxDxH)
Dimension (WxDxH)
155.3mm*147.9mm*62.2mm
VGA
VGA
Intel® HD Graphic
Color
Color
Black
Lock
Lock
Kensington Lock
