Specifications for
MPG Trident AS 12th
Marketing Name
Marketing Name
MPG Trident AS 12th
Operating System
Operating System
Windows 11 Pro
Windows 11 Home
Windows 11 Home
CPU
CPU
Intel® Core™ i7-12700
Intel® Core™ i7-12700F
Intel® Core™ i5-12400
Intel® Core™ i5-12400F
Intel® Core™ i7-12700F
Intel® Core™ i5-12400
Intel® Core™ i5-12400F
Storage
Storage
2x M.2 2280 SSD (Front 1x PCIe Gen 4, Rear 1x SATA/PCIe Gen 4 Auto Switch)
2x 2.5” Drive bays
2x 2.5” Drive bays
Memory
Memory
2x DDR4 3200MHz SO-DIMMs, up to 64GB
2x DDR4 2933Mhz SO-DIMMs, up to 64GB
2x DDR4 2933Mhz SO-DIMMs, up to 64GB
Sound
Sound
7.1 Channel HD Audio with Realtek ALC897
I/O (Front)
I/O (Front)
1x USB 2.0 Type A
1x USB 3.2 Gen 1 Type A
1x USB 3.2 Gen 1 Type C
1x Mic in / 1 x Headphone out
1x USB 3.2 Gen 1 Type A
1x USB 3.2 Gen 1 Type C
1x Mic in / 1 x Headphone out
I/O (Rear)
I/O (Rear)
2 x USB 2.0 Type A
3 x USB 3.2 Gen 2 Type A
1 x USB 3.2 Gen 2 Type C
1x HDMI™ (supports 4K @60Hz as specified in HDMI 2.0b)
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 120Hz
3 x Audio jacks
1 x RJ45(2.5G)
1 x Kensington Lock
*Tips: The display function is only available on non F series processors.
3 x USB 3.2 Gen 2 Type A
1 x USB 3.2 Gen 2 Type C
1x HDMI™ (supports 4K @60Hz as specified in HDMI 2.0b)
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 120Hz
3 x Audio jacks
1 x RJ45(2.5G)
1 x Kensington Lock
*Tips: The display function is only available on non F series processors.
Expansion Slots
Expansion Slots
1x PCIe 3.0 x16
LAN
LAN
Realtek RTL 8125BG (2.5G)
Cooling System
Cooling System
Air Cooler
Volume
Volume
10.36 L / 21.89pt
Dimension (WxDxH)
Dimension (WxDxH)
396.57 x 137.06 x 410.39 mm / 5.40 x 15.61 x 16.16 inches
With keyboard and mouse:548 x 284 x 524 mm / 21.57 x 11.18 x 20.63 inches
With keyboard and mouse:548 x 284 x 524 mm / 21.57 x 11.18 x 20.63 inches
VGA
VGA
MSI GeForce®RTX 3070 Ti VENTUS 3X 8G GDDR6X
MSI GeForce®RTX 3070 VENTUS 2X 8G GDDR6
MSI GeForce ®RTX 3070 VENTUS 2X 8G LHR GDDR6
MSI GeForce® RTX 3060 Ti VENTUS 2X V1 8G GDDR6
MSI GeForce®RTX 3060 Ti VENTUS 2X 8G V1 LHR GDDR6
MSI GeForce®RTX 3070 VENTUS 2X 8G GDDR6
MSI GeForce ®RTX 3070 VENTUS 2X 8G LHR GDDR6
MSI GeForce® RTX 3060 Ti VENTUS 2X V1 8G GDDR6
MSI GeForce®RTX 3060 Ti VENTUS 2X 8G V1 LHR GDDR6
Accessories
Accessories
1 x Manual (optional)
1 x Quick guide
1 x Warranty card
1 x Power cord
1 x Quick guide
1 x Warranty card
1 x Power cord
Software
Software
MSI Center
MSI App Player
Nahimic 3
XBOX Game Pass (30 days trial)
Tile
Norton(60 days trial)
MSI App Player
Nahimic 3
XBOX Game Pass (30 days trial)
Tile
Norton(60 days trial)
