| Show the Differences | P65 Creator 8RD | P65 Creator 8RE | P65 Creator 8RF |
| CPU |
Up to 8th Gen. Intel® Core™ i7 Processor |
Up to 8th Gen. Intel® Core™ i7 Processor |
Up to 8th Gen. Intel® Core™ i7 Processor |
|---|---|---|---|
| OS |
Windows 10 Pro Windows 10 Home |
Windows 10 Pro Windows 10 Home |
Windows 10 Pro Windows 10 Home |
| Chipset |
Intel® HM370 |
Intel® HM370 |
Intel® HM370 |
| Graphics |
GeForce® GTX 1050 Ti with 4GB GDDR5 |
GeForce® GTX 1060 With Max-Q Design, 6GB GDDR5 |
GeForce® GTX 1070 With Max-Q Design, 8GB GDDR5 |
| Memory |
DDR4-2400 DDR4-2666 Max 32GB 2 Slots |
DDR4-2400 DDR4-2666 Max 32GB 2 Slots |
DDR4-2400 DDR4-2666 Max 32GB 2 Slots |
| Storage Capability |
1x M.2 SSD slot (NVMe PCIe Gen3), 1x M.2 SSD Combo slot (NVMe PCIe Gen3 / SATA) |
1x M.2 SSD slot (NVMe PCIe Gen3), 1x M.2 SSD Combo slot (NVMe PCIe Gen3 / SATA) |
1x M.2 SSD slot (NVMe PCIe Gen3), 1x M.2 SSD Combo slot (NVMe PCIe Gen3 / SATA) |
| Security |
Fingerprint Security Discrete TPM2.0 |
Fingerprint Security Discrete TPM2.0 |
Fingerprint Security |
| Webcam |
HD type (30fps@720p) |
HD type (30fps@720p) |
HD type (30fps@720p) |
| Keyboard |
Single Backlit Keyboard (White) |
Single Backlit Keyboard (White) |
Single Backlit Keyboard (White) |
| Display |
15.6" FHD (1920x1080), IPS-Level |
15.6" FHD (1920x1080), IPS-Level |
– |
| Communication |
Gb LAN 802.11 ac Wi-Fi + Bluetooth v5 |
Gb LAN 802.11 ac Wi-Fi + Bluetooth v5 |
Gb LAN 802.11 ac Wi-Fi + Bluetooth v5 |
| Audio |
2x 2W Speaker |
2x 2W Speaker |
2x 2W Speaker |
| Audio Jack |
1x Mic-in, 1x Headphone-out |
1x Mic-in, 1x Headphone-out |
1x Mic-in, 1x Headphone-out (HiFi) |
| I/O Ports |
1x RJ45 1x Type-C USB3.1 Gen1 3x Type-A USB3.1 Gen1 1x HDMI™ (4K @ 30Hz) 1x Mini-DisplayPort |
1x RJ45 1x Type-C USB3.1 Gen1 3x Type-A USB3.1 Gen1 1x HDMI™ (4K @ 30Hz) 1x Mini-DisplayPort |
1x RJ45 1x Type-C (USB3.1 Gen2 / DP / Thunderbolt™3) 2x Type-C (USB3.2 Gen1 / DP / Thunderbolt™3) 2x Type-A USB3.1 Gen1 1x Type-A USB3.1 Gen2 1x HDMI™ 2.1 (4K @ 60Hz) 1x Mini-DisplayPort |
| Battery |
4-Cell 82 Battery (Whr) |
4-Cell 82 Battery (Whr) |
4-Cell 82 Battery (Whr) |
| Adapter |
150W adapter |
150W adapter |
180W Slim adapter |
| Dimension (WxDxH) |
357.7 x 247.7 x 17.9 mm |
357.7 x 247.7 x 17.9 mm |
357.7 x 247.7 x 17.9 mm |
| Weight (w/ Battery) |
1.88 kg |
1.88 kg |
1.88 kg |
