Processor

Supports 1st and 2nd Gen AMD^® RYZEN^™ THREADRIPPER^™ Series Processors for SocketTR4

See supported processors

Chipset

AMD^® X399 Chipset

Memory

• 8 x DDR4 memory slots, support up to 128GB
• Quad channel memory architecture¹
• Supports DDR4 3600+(OC)/ 3466(OC)/ 3333(OC)/ 3200(OC)/ 3066(OC)/ 2933(OC)/ 2800(OC)/ 2667(nonOC-by SPD)/2667(OC)/ 2400/ 2133 MHz²
• Supports ECC UDIMM memory

1. Please refer the DIMM Slots section for more details.
2. For the latest information about memory, please visit http://www.msi.com

Slots

• 2x PCIe 3.0 x16 slots (PCIE_1, PCIE_4)
• 2x PCIe 3.0 x8 slots (PCIE_3, PCIE_6)
• 2x PCIE 2.0 x1 Slots

Multi-GPU

• Supports 4-Way NVIDIA^® SLI™ Technology
• Supports 4-Way AMD^® CrossFire™ Technology

Storage

AMD^® X399 Chipset

• 8 x SATA 6Gb/s ports

AMD^® RYZEN THREADRIPPER Series Processors

• 3 x M.2 ports (Key M)
  • Supports up to PCIe 3.0 x4 and SATA 6Gb/s
  • M2_1, M2_3 slots support 2242/ 2260 /2280 storage devices
  • M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices

RAID

AMD^® X399 Chipset

• Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

USB

ASMedia^® ASM3142 Chipset

• 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panel
• 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel

AMD^® X399 Chipset

• 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port through the internal USB connector
• 4 x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors
• 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)

AMD^® CPU

• 8 x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel

Audio

Realtek^® ALC1220 Codec

• 7.1-Channel High Definition Audio
• Supports S/PDIF output

LAN

• 1 x Intel^® I211 Gigabit LAN controllers

Internal connectors

• 1 x 24-pin ATX main power connector
• 2 x 8-pin ATX 12V power connector
• 1 x 6-pin ATX 12V power connector¹
• 8 x SATA 6Gb/s connectors
• 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
• 1 x USB 3.1 Gen2 Type-C port
• 1 x 4-pin CPU fan connector
• 1 x 4-pin Water Pump connector
• 4 x 4-pin system fan connectors
• 2 x Front panel connectors
• 1 x Front panel audio connector
• 1 x 4pin RGB LED connector
• 1 x 4pin RAINBOW LED connector
• 1 x TPM module connector
• 1 x LED demo connector
• 1 x Rest Button
• 1 x Power Button
• 1 x OC Button
• 1 x Chassis Intrusion connector
• 1 x clear CMOS header

1. Provides additional power to PCIe x16 slots

Back panel ports

Dimensions

• 12 in. x 9.6 in. (30.4 cm x 24.3 cm)
• ATX Form Factor

Mounting

9 mounting holes

Operating System

• Support for Windows^® 10 64-bit
