Processor
Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
M.2 and SATA ports maximum support 1x M.2 PCIe SSD + 1x M.2 SATA SSD + 5x SATA HDDs. Please refer to page 34 for M.2 slots with examples of various combination possibilities.
The Turbo U.2 Host Card is not included, please purchase separately.
Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
RAID
Intel® Z370 Chipset
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1 for M.2 PCIe storage devices1
M.2 and SATA ports maximum support 1x M.2 PCIe SSD + 1x M.2 SATA SSD + 5x SATA HDDs. Please refer to page 34 for M.2 slots with examples of various combination possibilities.
USB
ASMedia® ASM3142 Chipset
1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panel
1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel
Intel® Z370 Chipset
8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
Audio
Realtek® ALC1220 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN
1 x Intel I219-V Gigabit LAN controller
Internal connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
6 x SATA 6Gb/s connectors
2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1 x 4-pin CPU fan connector
1 x 4-pin water pump fan connector
4 x 4-pin system fan connectors
1 x Front panel audio connector
2 x Front panel connectors
2 x 5050 RGB LED strip 12V connectors
1 x WS2812B Individually Addressable RGB LED strip 5V connector
1 x CORSAIR Individually Addressable RGB LED strip 5V connector
1 x TPM module connector
1 x Chassis Intrusion connector
1 x Clear CMOS jumper
Back panel ports
Keyboard / Mouse
USB 3.1 Gen1
Intel® Gigabit LAN
Golden Audio Connectors
USB 2.0
DisplayPort
USB 3.1 Gen2 Type-A/C
HDMI
USB 3.1 Gen1
Optical S/PDIF-Out
Dimensions
12 in. x 9.6 in. (30.4 cm x 24.3 cm)
ATX Form Factor
Mounting
9 mounting holes
Operating System
Support for Windows® 10 64-bit
Box content
MSI® does not guarantee the risks or damages caused by changing the cover.
These pictures are for reference only and may vary without notice.
