Processor
Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
Supports Intel® Smart Response Technology for Intel Core™ processors
Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
RAID
Intel® Z370 Chipset
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1 for M.2 PCIe storage devices1
M.2 PCIe RAID volume can be created with M.2 GENIE.
USB
ASMedia® ASM3142 Chipset
3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-C and 1 Type-A ports on the back panel,1 Type-C port available through the internal USB connector)
Intel® Z370 Chipset
8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
4 x USB 2.0 (High-speed USB) ports available through the internal USB connector
Audio
Realtek® ALC1220 Codec
Dual Realtek® ALC1220 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
WIFI & BLUETOOTH
Intel® Dual Band Wireless-AC 8265 card
The Wireless module is pre-install in the M2_3 (KeyE) slot.
Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 867 Mbps speed.
2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1 x 4-pin CPU fan connector
1 x 4-pin water pump fan connector
3 x 4-pin system fan connectors
1 x Front panel audio connector
2 x Front panel connectors
1 x Serial port connector
1 x RGB LED connector
1 x TPM module connector
1 x Chassis Intrusion connector
1 x Clear CMOS jumper
Back panel ports
Intel Wi-Fi & Bluetooth
Mouse
DisplayPort
Intel® Gigabit LAN
Golden Audio Connectors
Keyboard
HDMI
USB 3.1 Gen2 Type-A/C
USB 3.1 Gen1
USB 3.1 Gen1
Optical S/PDIF-Out
Dimensions
9.6in. x 9.6 in. (24.4 cm x 24.4 cm)
m-ATX Form Factor
Mounting
9 mounting holes
Operating System
Support for Windows® 10 64-bit
Box content
MSI® does not guarantee the risks or damages caused by changing the cover.
These pictures are for reference only and may vary without notice.
